Technical Overview
Frameset
Frame:
Fourstroke LT AMP Carbon | APS Suspension System | 120mm Travel | Integrated Battery | Fully Guided Internal Cable Routing | Post Mount Disc | 12 x 148mm Boost Thru-Axle
Suspension
Front Suspension:
RockShox SID SL Select+
Rear Suspension:
RockShox SIDLUXE Select+
E-System
Drive Unit:
TQ-HPR50 Drive Unit
Battery Pack:
TQ Battery | 360 Wh | Certified by UL LLC
Display:
TQ VO2 Display | 2" O-LED | Bluetooth / ANT+
Drive Unit Control:
TQ V01 Remote
Charger:
TQ-HPR50 4A Charger
Cockpit
Stem:
Truvativ Atmos 7K
Handlebar:
BMC MRB 01 Carbon | 760mm
Seat
Seatpost:
Bikeyoke Divine
Saddle:
Fizik Antares R5
Drivetrain
Crankset:
Praxis Carbon eCrank | SRAM X Sync
Chainrings:
34T
Cassette:
SRAM GX XG-1275 Eagle
Cassette Size:
10-52T
Chain:
SRAM GX Eagle
Rear Derailleur:
SRAM GX Eagle AXS
Shifters:
SRAM AXS Controller
Gears:
1 x 12
Brakes
Brake Levers / Calipers:
SRAM G2 RSC
Rotors:
SRAM Centerline
Rotor Size (F/R):
180 / 180mm
Wheels
Rims:
DT Swiss XRC 1501 | 30mm Inner Width
Hubs (F/R):
DT Swiss 240 Straightpull | Ratchet EXP 36
Tires:
Maxxis Rekon 2.4" | EXO TR
Additional Information
Tire Clearance:
60mm measured tire
Weight without Pedals:
16.65 kg
ASTM Classification:
Level 3
System Weight Limit:
110kg
General Product Safety Regulation (GPSR):
Safety Instructions GPSR (EU)
Responsible person according to GPSR (EU)
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height | <172 | 172-182 | 180-188 | >188 |
| Reach | 437 | 457 | 476 | 496 |
| Stack | 594 | 605 | 615 | 627 |
| Bar Rise | 20 | 20 | 20 | 20 |
| Bar Sweep | 7.5° | 7.5° | 7.5° | 7.5° |
| Bar Width | 760 | 760 | 760 | 760 |
| BB Drop | 40 | 40 | 40 | 40 |
| Crank Length | 165 | 170 | 170 | 170 |
| Fork Length | 531 | 531 | 531 | 531 |
| Fork Rake | 44 | 44 | 44 | 44 |
| Front Center | 725 | 751 | 775 | 800 |
| Head Tube | 90 | 102 | 113 | 125 |
| Head Tube Angle | 66.5° | 66.5° | 66.5° | 66.5° |
| Rear Center | 435 | 435 | 435 | 435 |
| Seat Angle | 77° | 77° | 77° | 77° |
| Seat Tube | 420 | 430 | 470 | 490 |
| Seatpost Drop | 125 | 160 | 160 | 185 |
| Seatpost Length | 365 | 435 | 435 | 485 |
| Seatpost Offset | 0 | 0 | 0 | 0 |
| Standover Height | 730 | 730 | 730 | 730 |
| Stem Angle | ±6° | ±6° | ±6° | ±6° |
| Stem Length | 40 | 50 | 50 | 60 |
| Top Tube | 574 | 597 | 620 | 644 |
| Trail | 115 | 115 | 115 | 115 |
| Wheelbase | 1157 | 1178 | 1202 | 1227 |
