Technische Übersicht
Rahmenset
Rahmen:
URS Premium Carbon with Micro Travel Technology | Tuned Compliance Concept Gravel | Gravel+ Geometry | Internal Cable Routing | Fender and Rack Mounts | Integrated Seatpost Clamp | Flat Mount Disc | 12 x 142mm Thru-Axle
Gabel:
URS Premium Carbon with Tuned Compliance Concept Gravel | Internal bRake & Hub Dynamo Cable Routing | Fender Mounts | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Vorbau:
BMC MSM 02
Lenker:
Easton EA50 AX
Sattel
Sattelstütze:
URS Premium Carbon D-Shaped Seatpost | 0mm Offset
Sattel:
WTB SL8 Steel | Medium
Antrieb
Kurbel:
SRAM Apex 1
Kettenblätter:
40T
Kassette:
SRAM PG-1130 APEX
Kassettengrösse:
11-42T
Kette:
SRAM Apex
Schaltwerk:
SRAM APEX 1 Long Cage
Schalthebel:
SRAM Apex 1 HRD
Übersetzung:
1 x 11
Tretlager:
PF86 Bottom Bracket
Bremsen
Bremshebel:
SRAM Apex HRD
Bremsscheiben:
SRAM Centerline
Bremsscheibengrösse (V/H):
180 / 160mm
Räder
Felgen:
DT Swiss C1850 SPLINE | 23mm
Naben (V/H):
DT Swiss 370 Spline Disc
Bereifung:
WTB Raddler | 44mm
Weitere Informationen
Reifenfreiheit:
42mm measured tire
ASTM-Klassifizierung:
Level 2
Maximales Systemgewicht:
120kg
Produktsicherheitsverordnung (GPSR):
Sicherheitshinweise GPSR (EU)
Verantwortliche Person gemäss GPSR (EU)
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height | <170 | 172-180 | 178-188 | 186-196 |
| Reach | 403 | 415 | 419 | 429 |
| Stack | 538 | 569 | 603 | 641 |
| Bar Drop | 120 | 120 | 120 | 120 |
| Bar Reach | 80 | 80 | 80 | 80 |
| Bar Width | 420 | 420 | 440 | 440 |
| BB Drop | 69 | 69 | 69 | 69 |
| Crank Length | 170 | 172.5 | 172.5 | 175 |
| Fork Length | 407 | 407 | 407 | 407 |
| Fork Rake | 45 | 45 | 45 | 45 |
| Front Center | 625 | 648 | 665 | 700 |
| Head Tube | 113 | 146 | 172 | 207 |
| Head Tube Angle | 70 | 70 | 70 | 70 |
| Rear Center | 425 | 425 | 425 | 425 |
| Seat Angle | 74 | 74 | 74 | 74 |
| Seat Tube | 431 | 459 | 492 | 527 |
| Seatpost Length | 330 | 380 | 430 | 430 |
| Standover Height | 748 | 778 | 810 | 846 |
| Stem Length | 70 | 70 | 80 | 90 |
| Top Tube | 557 | 578 | 591 | 612 |
| Trail | 77 | 77 | 77 | 77 |
| Wheelbase | 1041 | 1064 | 1081 | 1105 |
