Technische Übersicht
Rahmenset
Rahmen:
257 AMP Premium Aluminium | Smoothwelded | Integrated Battery | Internal Cable Routing | Powder Coat Finish | Flat Mount Disc | Internal Gear Hub dropouts
Gabel:
257 Premium Aluminium | Fender Mounts | Post Mount Disc | 12 x 100mm Thru-Axle
E-System
Motor:
Bosch Performance CX Smart System
Akku:
Bosch PowerTube | 625 Wh | Certified by Intertek Testing Services NA, Inc.
Display:
Bosch Kiox 300
Steuerung der Antriebseinheit:
Bosch Led Remote
Ladegerät:
Bosch 4A Charger
Cockpit
Vorbau:
ICS MTT x Redshift Suspension Stem | Integrated Cockpit System Technology
Lenker:
BMC LSB 01
Sattel
Sattelstütze:
BMC LSP 02
Sattel:
Selle Royal Vivo
Antrieb
Kurbel:
Miranda Classic x Bosch | Gates CDX
Kettenblätter:
46T
Kassette:
Gates CDX
Kassettengrösse:
22T
Kette:
Gates Belt 113 CDN
Schalthebel:
SHIMANO Alfine SL-S7000 | Rapidfire Plus
Übersetzung:
1 x 8
Bremsen
Bremshebel:
TEKTRO TRP HD-EU832
Bremsscheiben:
TEKTRO RC01E
Bremsscheibengrösse (V/H):
180 / 160mm
Räder
Felgen:
E-SRX30
Naben (V/H):
CL-712 | SHIMANO Alfine 8
Bereifung:
Pirelli Angel GT | 37mm
Weitere Informationen
Reifenfreiheit:
42mm measured tire
ASTM-Klassifizierung:
Level 2
Maximales Systemgewicht:
120kg
Produktsicherheitsverordnung (GPSR):
Sicherheitshinweise GPSR (EU)
Verantwortliche Person gemäss GPSR (EU)
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height | <168 | 168 - 180 | 178 - 190 | >190 |
| Reach | 424 | 424 | 425 | 436 |
| Stack | 560 | 590 | 620 | 645 |
| Bar Sweep | 9° | 9° | 9° | 9° |
| Bar Width | 680 | 680 | 680 | 680 |
| BB Drop | 67 | 67 | 67 | 67 |
| Crank Length | 170 | 170 | 170 | 170 |
| Fork Length | 408 | 408 | 408 | 408 |
| Fork Rake | 45 | 45 | 45 | 45 |
| Front Center | 665 | 665 | 677 | 699 |
| Head Tube | 133 | 165 | 197 | 225 |
| Head Tube Angle | 70° | 70° | 70° | 70° |
| Rear Center | 428-441 | 428-441 | 428-441 | 428-441 |
| Seat Angle | 75° | 75° | 75° | 75° |
| Seat Tube | 480 | 510 | 540 | 570 |
| Seatpost Length | 350 | 350 | 350 | 350 |
| Seatpost Offset | 15 | 15 | 15 | 15 |
| Standover Height | 766 | 794 | 819 | 847 |
| Stem Angle | 0° | 0° | 0° | 0° |
| Stem Length | 72 | 72 | 80 | 90 |
| Top Tube | 574 | 582 | 591 | 609 |
| Trail | 75 | 75 | 75 | 75 |
| Wheelbase | 1073-1086 | 1084-1097 | 1096-1109 | 1117-1130 |
