Name: Timemachine ROAD 01 TWO
Brand: BMC
SKU: 30001451
Price: 7999.0 USD
Availability: OutOfStock

BMC Bikes | Timemachine ROAD 01 TWO ANTHRACITE

Farbe: Anthracite
Modelljahr: 2022

BMC Archive Produkt

Kompatible Teile und Zubehör

[{"id":40929380368463,"title":"47","option1":"47","option2":null,"option3":null,"sku":"30001451","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Timemachine ROAD 01 TWO - 47","public_title":"47","options":["47"],"price":799900,"weight":12,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630027872132","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40929380401231,"title":"51","option1":"51","option2":null,"option3":null,"sku":"30001452","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Timemachine ROAD 01 TWO - 51","public_title":"51","options":["51"],"price":799900,"weight":12,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630027872125","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40929380433999,"title":"54","option1":"54","option2":null,"option3":null,"sku":"30001453","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Timemachine ROAD 01 TWO - 54","public_title":"54","options":["54"],"price":799900,"weight":12,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630027872118","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40929380466767,"title":"56","option1":"56","option2":null,"option3":null,"sku":"30001454","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Timemachine ROAD 01 TWO - 56","public_title":"56","options":["56"],"price":799900,"weight":12,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630027872101","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40929380565071,"title":"58","option1":"58","option2":null,"option3":null,"sku":"30001455","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Timemachine ROAD 01 TWO - 58","public_title":"58","options":["58"],"price":799900,"weight":12,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630027872095","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40929380597839,"title":"61","option1":"61","option2":null,"option3":null,"sku":"30001456","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Timemachine ROAD 01 TWO - 61","public_title":"61","options":["61"],"price":799900,"weight":12,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630027872088","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Technische Übersicht

Rahmenset

Rahmen:
Timemachine Road 01 Premium Carbon with Aero Module Tuned Compliance Concept Speed | ICS Aero Technology Stealth Cable Routing | Integrated Seatpost clamp | Flat Mount Disc | 12 x 142mm Thru-Axle

Gabel:
Timemachine Road 01 Premium Carbon with Integrated Aero Cover Tuned Compliance Concept Speed | ICS Technology Stealth Cable Routing | Flat Mount Disc | 12 x 100mm Thru-Axle | 48mm offset (Size 47-51) 43mm offset (Size 54-61)

Cockpit

Vorbau:
BMC ICS Aero | Integrated Aero Cockpit Design

Lenker:
BMC ICS Aero | Aero Top Shape | Compact Bend

Sattel

Sattelstütze:
Timemachine Road 01 Premium Carbon Aero Seatpost | 0 | 15 | 30mm adjustable Offset

Sattel:
Fizik Argo Vento R5 | 140mm

Antrieb

Kurbel:
SHIMANO Ultegra FC-R8100

Kettenblätter:
52-36T

Kassette:
SHIMANO Ultegra CS-R8100

Kassettengrösse:
11-30T

Kette:
SHIMANO CN-M8100

Umwerfer:
SHIMANO Ultegra Di2 FD-R8150

Schaltwerk:
SHIMANO Ultegra Di2 RD-R8150

Schalthebel:
SHIMANO Ultegra Di2 ST-R8170

Übersetzung:
2 x 12

Tretlager:
PF86 Bottom Bracket

Bremsen

Bremshebel:
SHIMANO Ultegra BR-R8170

Bremsscheiben:
SHIMANO RT-MT800

Bremsscheibengrösse (V/H):
160 / 140mm

Räder

Felgen:
CRD-501 SL Carbon | Tubeless Ready | 50mm

Naben (V/H):
CRD-501 SL

Bereifung:
Vittoria Corsa | 25mm

Zubehör

Lieferumfang:
Aerocore Bottle Cages

Weitere Informationen

Reifenfreiheit:
28mm measured tire

ASTM-Klassifizierung:
Level 1

Maximales Systemgewicht:
110kg

Produktsicherheitsverordnung (GPSR):
Sicherheitshinweise GPSR (EU)
Verantwortliche Person gemäss GPSR (EU)

Size	47	51	54	56	58	61
Rider Height	<166	166-174	172-180	178-186	184-192	>190
Reach	373	381	390	395	405	413
Stack	496	520	540	555	574	598
Bar Drop	122	122	122	122	122	122
Bar Reach	66	66	66	66	66	66
Bar Width	400	420	420	420	420	440
BB Drop	70	70	70	70	70	70
Crank Length	170	170	172.5	172.5	175	175
Fork Length	379	379	374	374	374	374
Fork Rake	50	50	45	45	45	45
Front Center	577	592	594	604	620	636
Head Tube	88	113	135	150	170	196
Head Tube Angle	71.2	71.2	72	72	72	72
Rear Center	410	410	410	410	410	410
Seat Angle	73.5	73.5	73.5	73.5	73.5	73.5
Seat Tube	480	518	548	568	588	611
Seatpost Length	210	210	270	270	270	270
Seatpost Offset	0 / 15 / 30	0 / 15 / 30	0 / 15 / 30	0 / 15 / 30	0 / 15 / 30	0 / 15 / 30
Standover Height	743	774	799	816	834	858
Stem Angle	-15	-15	-15	-15	-15	-15
Stem Length	100	100	110	110	110	120
Top Tube	520	535	550	560	575	590
Trail	62	62	62	62	62	62
Wheelbase	975	991	994	1004	1020	1036

ICS Aero Clip-on Extensions
